Side-Beam X-Ray Inspection System for Bottles, Cans and Jars
Model: XR-5000D
QuickFacts
• Model: XR-5000D
• Product Type: Side-beam X-ray inspection for bottles, cans and jars
• Key Size / Channel: Standard 160×230mm; optional 180×250mm or customized sizes; some configurations may use 220×350mm
• Inspection Targets: Metal contaminants, Glass fragments, Stone particles, Ceramic pieces, Dense foreign objects inside bottles, cans or jars, Foreign objects near container bottom or side-wall areas depending on container structure
• Installation Type: Inline bottle / can / jar production line integration
• Configuration: Final tunnel, speed, rejection and safety setup should be confirmed by product and site layout
› Food X-Ray Inspection
› Bulk Material X-Ray
› Fish Bone X-Ray
› Bottle & Can X-Ray
› Industrial X-Ray
› Industrial X-Ray
› Conveyor Metal Detector
› Pipeline Metal Detector
› Free Fall Metal Detector
› Needle Detector
› Dynamic Checkweigher
› Food Checkweigher
› Package Checkweigher
› Sealing Inspection System
› Combo Inspection System
› Air Jet
› Pusher
› Flap
› Drop-Down
› Customized Rejector
Product Overview
The LITUBO XR-5000D is a side-beam X-ray inspection system designed for bottles, cans, jars and upright containers. It is suitable for customers whose products cannot be effectively inspected by top-down X-ray only, especially when the package shape, bottom structure or container wall may create blind inspection areas.
For beverage, canned food, sauce, condiment and jar product lines, the XR-5000D helps inspect contaminants inside sealed containers and supports safer final product release before shipment.
Typical Applications
• Bottles
• Cans
• Jars
• Sealed tin cans
• Sauce bottles
• Condiment jars
• Beverage containers
• Upright packaged food and beverage products
Detection Targets
• Metal contaminants
• Glass fragments
• Stone particles
• Ceramic pieces
• Dense foreign objects inside bottles, cans or jars
• Foreign objects near container bottom or side-wall areas depending on container structure
Working Principle
Containers pass through the side-beam X-ray inspection area in an upright position. The side beam scans the product from the side instead of only from the top. The system analyzes density differences inside the container and identifies suspicious contaminants. When a defect is detected, the system triggers sound and light alarm and can activate a pusher rejection system.
Technical Specifications
Working Principle
Quotation Reminder
Actual inspection performance depends on container material, container diameter, product density, filling level, line speed, inspection angle and rejection method. Please provide bottle / can / jar samples, container drawings or production line information to LITUBO for configuration review and quotation.
Configuration Options
• Single-beam or dual-beam inspection
• Inspection height and width according to bottle or can size
• Pusher rejection according to container weight and speed
• Conveyor guide rail according to container shape
• Conveyor speed matched with filling, sealing or labeling line
• Product recipe setting according to container material and product density
• Integration with filling, capping, sealing, labeling or packing line
The XR-5000D is typically installed after filling, sealing, capping or labeling, and before final packing or shipment. It is suitable for upright container lines where side inspection is needed to reduce blind zones and improve final quality control.
