Semi-Automatic Side Sealing Carton Sealer

FX-5045

Ask Questoin

FX-5045 is a side sealing carton sealer, not a standard top-bottom carton sealer. It is suitable for side-opening cartons, such as beverage and tile packaging, and completes tape sealing on both side openings in one pass.

Reliable Semi-Automatic Carton Sealing

Designed for manual-assisted packing stations, these machines help operators complete carton sealing faster and more consistently than manual taping.

Top, Bottom and Side Sealing Options

The range covers standard top-and-bottom sealing, taller carton sealing, self-adaptive sealing, and side sealing for special carton openings.

Easy Adjustment for Daily Packing Work

The range covers standard top-and-bottom sealing, taller carton sealing, self-adaptive sealing, and side sealing for special carton openings.

Clean Carton Finish with Lower Labor Effort

Tape sealing creates a neater carton appearance while reducing repetitive hand taping, folding, and adjustment work in everyday packing operations.

Key Features and Benefits

Side Opening Carton Sealing

Designed for cartons with side openings, such as beverage cartons, tile cartons and similar packaging formats.

Two-Side Tape Sealing in One Pass

Completes tape sealing on both side openings in one operation, improving side-sealing efficiency.

Clean and Standardized Sealing Appearance

Produces flat, neat and standardized side sealing for better finished carton presentation.

Stable and Durable Structure

The brochure emphasizes stable performance, reliable quality and long service life.

Fast and Easy Adjustment

Designed for economical and quick sealing with simple adjustment for daily operation.

Strong Application Fit for Special Cartons

A more suitable choice than standard top-bottom sealers when carton openings are located on the side.

Technical Specifications

Specifications are for reference only. Final configuration should be confirmed according to carton size, tape width, power supply and line layout.

specNameEn	unit	FX-5050	FX-5050Z	FX-5045	FX-6050
Machine Type		Semi-Automatic Side Belt Drive Carton Sealer	Semi-Automatic Self-Adaptive Carton Sealer	Semi-Automatic Side Sealing Carton Sealer	Semi-Automatic Top and Bottom Belt Drive Carton Sealer
Power Supply		220V, 50Hz	220V, 50Hz	220V, 50Hz	220V, 50Hz
Power		200W	200W	200W	200W
Maximum Carton Size	mm	L unlimited × W500 × H500	L unlimited × W500 × H500	L unlimited × W500 × H450	L unlimited × W500 × H600
Minimum Carton Size	mm	L150 × W150 × H120	L150 × W150 × H150	L150 × W250 × H90	L150 × W150 × H150
Packing Speed	cartons/min	8–15	5–10	8–15	8–15
Tape Width	mm	48 / 60 / 75, choose one	48 / 60 / 75, choose one	48 / 60 / 75, choose one	48 / 60 / 75, choose one
Machine / Outer Packing Size	mm	L1050 × W850 × H1350, excluding front/rear roller stand	L1200 × W900 × H1350, excluding front/rear roller stand	L900 × W950 × H1350, excluding front/rear roller stand	L1050 × W850 × H1350, excluding front/rear roller stand
Machine Weight	kg	130	170	150	130

Video

Downloads

Resources & Downloads

Document.pdf

Works with PLC

Used as the operator interface f

达到

Document.pdf

Works with PLC

Used as the operator interface f

达到

Discover More

Related Products

PLC Series

FAQs

Is FX-5045 a standard top-bottom sealer?

No. It is a side sealing carton sealer for side-opening cartons.

What type of cartons are these semi-automatic carton sealers suitable for?

They are suitable for standard corrugated cartons used in manual-assisted packing stations. Different models can handle top-and-bottom sealing, taller cartons, self-adaptive size changes, or side-opening cartons.

When should I choose FX-5050Z?

FX-5050Z is recommended when carton sizes change frequently. It can automatically adjust width and height, making it suitable for small-batch and mixed-size carton packing.

What applications fit FX-5045?

It is beverage cartons, tile cartons and similar side-opening packaging formats.

What is the difference between FX-5050 and FX-6050?

FX-5050 uses side belt drive and is suitable for cartons up to 500 mm high. FX-6050 uses top and bottom belt drive and can handle taller cartons up to 600 mm high.

When should I choose FX-5045?

FX-5045 is designed for side-opening cartons, such as beverage cartons, tile cartons, and similar packaging formats. It seals both side openings in one pass.
